Top Online UPS Manufacturers in UAE | Technovision Energy
TechnoVision Energy Pvt Ltd. is leading Online UPS manufacturers in UAE, traders, wholesalers in UAE. The Online UPS are designed using the latest power electronics and embedded technologies to ensure stable power output, efficiency and seamless back-up performance. Our Online UPS Range is based on double conversion technology and has 25 years of experience. The inverter then converts the power back to clean and regulated AC power which is on-going to the connected load. Rectification of AC power to DC power, simultaneous charge of Battery bank.
About Online UPS
An Online UPS (Uninterruptible Power Supply) is a power backup device that always provides clean and regulated power to the equipment it is connected to with double-conversion technology. Online UPS systems are commonly found in the data centers, hospitals, industries and IT infrastructure. It is able to convert incoming power during outages without any transfer time and insures against voltage fluctuations, surges and frequency variations affecting sensitive equipment.
Online UPS Traders and Wholesalers in UAE
We provide reliable power back up services to industry, commercial and institutional customers. As we are Online UPS traders in UAE, we have a wide range of products that meet various capacity needs and are quality, reliable and delivered in a timely manner. Our emphasis is on both cost-effective power protection solutions and technical expertise and responsive customer support.
Product we Offers of Online UPS:
As leading online UPS manufacturers in UAE, following are the products that we are offering.
| Online UPS 1Ø - 1Ø: 3KVA – 10KVA: | This is a single-phase online UPS that takes a single-phase input and provides a single-phase output, typically used for smaller to medium-sized loads like servers or workstations. |
| Online UPS 3Ø - 1Ø: 5KVA – 60KVA: | This is a three-phase input, single-phase output online UPS, ideal for applications where the power source is three-phase but the connected equipment requires a single-phase supply. |
| Online UPS 3Ø - 3Ø: 5KVA – 500KVA: | This is a high-capacity three-phase online UPS that takes a three-phase input and provides a three-phase output, commonly used to power large industrial machinery. |
Types of Online UPS
As Online UPS wholesalers in UAE, we provided different types of our online UPS according to design and servers which are given below.
- Ferroresonant Online UPS - It is topology that is still popular in severe electrical situations, but is getting older, that uses a transformer of a certain type.
- Centralized UPS: A single UPS is large and it is used for powering multiple devices or the entire facility. In this way management is simplified and the arrangement can be more economical if large scale power protection is needed.
- Industrial Grade UPS - Hard and tough, can handle extreme industrial conditions such as high temperatures, dust and vibration. Provide high quality security to valuable control systems and heavy machines.
- Specialty Grade UPS: Systems like the Naval grade, Défense grade UPS etc are designed to satisfy the strict military or naval requirement. These are constructed to be very strong and dependable in highly specialized and demanding applications.
- Modular UPS: These online UPS range systems are made up of power modules which can be added or removed to increase or decrease the UPS capacity as required. They are user-friendly, simple to maintain and exceedingly redundant for growing enterprises.
- Double Conversion Online UPS - It is the industry standard for mission-critical applications such as data centers, hospitals or heavy duty servers.
- Delta Conversion Online UPS - In the more common double-conversion design, which is often found in larger industrial systems, it is an advanced energy-efficient design.
Technical Specification of Online UPS:
As online UPS manufacturers in UAE, we have added below a technical sheet that provides more technical information such as:
| Feature | Online UPS 1 KVA (1Ø-1Ø) | Online UPS 3.1 KVA (3Ø-1Ø) | Online UPS 3.3 KVA (3Ø-3Ø) |
|---|---|---|---|
| Technology | IGBT based PWM Technology, Double Conversion, True Sine Wave | DSP based, IGBT Inverter-IGBT Converter | DSP based, IGBT Inverter-IGBT Converter |
| Input Voltage | 230VAC, 1Ø | 415VAC, 3Ø & N | 415VAC, 3Ø & N |
| Input Voltage Window | 170VAC - 270VAC | 360VAC - 460VAC, 330VAC - 470VAC | 330VAC - 470VAC, 360VAC - 460VAC |
| Input Power Factor | 0.99 on full load | > 0.95 | > 0.95 |
| Input Frequency | 50Hz ± 10% | 45-55Hz | 45-55Hz |
| Input Current Harmonic Distortion | <7% @ 100% Load | Not specified | Not specified |
| Output Nominal Voltage | 230V/50Hz | 230VAC, 1Ø, P-N | 415VAC, 3Φ, P-P / 230VAC, 1Φ, P-N |
| Output Frequency | 50Hz ± 0.1Hz | 50 Hz ± 0.1Hz | 50 Hz ± 0.1Hz |
| Efficiency | 85-90% | > 90% | Not specified |
| Output Power Factor | 0.8 lagging | 0.8 lagging to Unity | 0.8 lagging to Unity |
| Overload Capacity | 125% for 1 minute, 150% for 10 seconds | 100% Continuous, 110% for 10 minutes, 150% for 1 minute | 100% Continuous, 110% for 10 minutes, 150% for 1 minute |
| Total Harmonic Distortion (THD) | <2% for linear load, <4% for non-linear load | <2% for linear load, <5% for non-linear load | <2% for linear load, <5% for non-linear load |
Features/Characteristics of Online UPS:
As leading online UPS in UAE, according to operating efficiency we provided different benefits which are given below.
- Zero Transfer Time: UPS with inbuilt Isolation transformer is essential when dealing with sensitive equipment that cannot withstand even one millisecond of downtime.
- Pure Sine Wave Output: Online UPS traders are necessary to prevent the damage of sensitive electronic devices and to make sure customized UPS will be able to perform their duties correctly.
- Voltage and Frequency Regulation: This helps protect your equipment against sags, swells and variation of frequencies that can damage delicate equipment.
- Galvanic Isolation: Naval grade UPS provides physical separation that ensures there is no conduction of electrical noise and surges caused by the input source to the equipment to which Parallel Redundant UPS is connected.
- Fast Operating Profile: Modern online UPS systems are built with high operating efficiency, Defense grade UPS which contributes to less energy usage and less operating costs in the long term.
Industries We Serve for Online UPS:
Serve as prominent Online UPS traders and wholesalers in UAE, these are applicable in different sites which are given below.
- Financial Institutions: ATM securities, bank server and bank security systems. Make sure that transactions and data are still running in power protection UPS.
- Information Technology Infrastructure: Online UPS wholesalers helps to eliminate corruption of data and provides the business with the ability to operate continuously around the clock on essential business services.
- Hospitals and Healthcare Facilities: Powers life-support devices, diagnostic equipment and patient monitoring devices. Parallel Redunandant UPS provides a stable and predictable power supply of vital medical procedures.
- Intrusion Prevention: Removes production downturns caused by fluctuating power, a lost product and damaged equipment in Surge protection UPS. Defends PLCs, robotics and automated lines.
- Telecommunications: Provide emergency power to network switching equipment, communication towers and base stations. Gives a seamless line-interactive UPS backup point and network in case of power outage.
Why Choose Us for Online UPS?
- Very Reliable: IGBT online UPS systems are highly efficient and very reliable so that we get maximum uptime and minimum loss.
- Quality Assurance: To last longer than other products, our products are produced using robust industrial designs, and quality materials.
- Expert Assistance: Hybrid UPS staff can provide a full scope of technical support, such as consultation, installation, and maintenance services.
TechnoVision Energy Pvt Ltd. is trusted online UPS manufacturers in UAE, traders, wholesalers in UAE. To be applied to mission-critical applications is online UPS. The benefits of our double-conversion technology include a stable, continuous and uninterrupted supply of clean power which protects valuable equipment against all but the most extrem
