Features
- Sine wave supply
- Designed for Industrial purpose
- Digital IGBT design
- Sleek in size
- Rugged product design
- Fast Change over at higher load
- Automatic operation
| Technology | DSP based, IGBT inverter-IGBT converter Online UPS. |
|---|---|
| DC BUS | 240VDC – 480VDC |
| Rating | 10KVA – 500KVA |
| Input Voltage | 415VAC, 3Ø & N |
| Input Voltage Window | 330VAC – 470VAC, 360VAC – 460VAC |
| Input PFC - 100% Load | > 0.95 |
| Power walk in | Soft start for 0-20 seconds power walk-in. |
| Input Frequency | 45-55Hz |
| Inverter Type | IGBT-based MPWM with instantaneous Sinewave Control | ||||||
|---|---|---|---|---|---|---|---|
| Nominal Voltage | 415VAC, 3Φ, P-P / 230VAC, 1Φ, P-N | ||||||
| Output PF | 0.8 lagging to Unity | ||||||
| Regulation | ( ± ) 1% | ||||||
| Waveform | True Sinewave | ||||||
| Frequency | 50 Hz ± 0.1Hz | ||||||
| Total Harmonic Distortion |
|
||||||
| Transient Response | Remains within +/- 5% & recover to normal within 20 msec | ||||||
| Over Load Capacity |
|
||||||
| Mode of Operation | Designed for Continuous operation | ||||||
| Isolation | True Online with complete galvanic isolation. | ||||||
| Crest Factor | 3:1 | ||||||
| Inverter Protection | Advanced Electronic Protection for device safety backed up with MCB’s/ MCCBs & fast acting fuses, high speed pulse by pulse electronic device protection over voltage / under voltage protection, Electronic over current trip. | ||||||
| Alarms |
|
||||||
| LED Indications (Single LED with multi function) |
|
| Manual Bypass | Provided |
|---|
| Type | IGBT based full bridge |
| Voltage Regulation | ( ± ) 1% |
| Ripple Voltage | < 2% |
| Converter Protection | Advanced Electronic Protection for device safety backed up with MCB’s/ MCCBs & fast acting fuses |
