| Related Standards |
IS 2026, IS 11171 |
| Ratings |
40 - 500 KVA, 1 - 20 KVA for single phase |
| Input Voltage |
415 VAC - 3Ph |
| Output Voltage |
110 VAC, 220 VAC, 250 VAC, 415 VAC - 3Ph |
| Acceptable Input Range |
±10% |
| Efficiency |
98% @ 100% Load |
| Regulation |
2-4% for 100% change in load at Unity P.F. |
| Impedance |
< 2% |
| Connection |
Delta-Star, Star-Delta, Star-Star |
| Operating Load Power Factor |
0.75 Lagging to 0.9 Leading |
| DC Galvanic Isolation |
> 1000 Mega Ohms |
| Common mode noise rejection |
120 DB up to 10Khz 70 DB for range 10 Khz to 50 Khz, 50 DB for range 50 Khz to 1Mhz |
| Dielectric Strength |
2.5 KV, 50Hz for 1 Minute |
| Coupling Capacitance |
0.01 Pico Farads |
| Line Leakage Current |
< 20 Micro Amps |
| Operating Temperature |
-10 to +55 C |
| Insulation |
Class F |
| Core & Winding |
CRGO and Aluminum Winding (Copper winding on request) |
| Degree Of Protection |
IP21 (Other ingress protection on Request) |
| Color |
Siemens Grey RAL7035 (Customizable) |
| Type of Cooling |
Forced Cooling as per design requirement |
| Metering |
Digital |
